[Warning] Warning

This section not yet updated for Inkscape v0.92.

Tricks

It is possible to exploit the Tiling dialog to produce a number of useful effects. The most interesting is placing tiles along an arc or spiral.

To put a tile along an arc use the P1 symmetry with one row of tiles. Check the Exclude tile box. The Rotation center is used as the center of rotation.

Tiles on an arc.
The base tile is drawn on the left, showing the Rotation center of the tile. On the right is after a P1 tiling with a per column shift removed by checking the Exclude tile box and with a rotation of 60%.

The next figure shows how 12 stars can be put in a circle. This would have been an alternative way of placing the stars in the European Union flag if the stars did not need to be placed with one of their points straight up.

Tiles on an arc 2.
Twelve stars in a circle.

This trick can also place objects along a spiral by specifying that the tile should get larger with each column. One can put the stars on a logarithmic spiral so that the stars don't run into each after several loops.

Tiles on an arc 3.
Stars on a logarithmic spiral. The tile size is increased by 2.5% with Base set to 2.7. Each tile is rotated 20°.
Tiles on an arc 4.
Stars on a logarithmic spiral. The tile size is increased by 2.5% with Base set to 2.7. Each tile is rotated 20°. The per column shift has been set to 60% (with the Exclude tile box checked).
A P1 symmetry tiling with a rotation 4.
A P1 symmetry tiling. 8 rows, 21 columns. Rotation of −11.5° per row and 20.6° per column, Scale of 39.3% per row and 24.2% per column with a Base of 2.7 for both x and y. The pattern matches that for a pine cone with 8 rows in one direction and 13 in the other. For the mathematicians: note that 13 times the per column scaling is equal to 8 times the per row scaling and that 13 times the per column rotation minus 8 times the per row rotation is equal to 360°. This is due to the constraint that the 14th star in the first row is the same as the 9th star in the first column.
Circle tiled in circle.
A circle tiled on an arc. The red circle with the Rotation center moved off center was the source tile.
